Description
Field of application:
Longitudinal and cross-cuts Tapered and profiled Kerf cuts and flaps Shift cuts and diagonal kerfs (two-man operation) Use of materials e.g. solid wood and glulam beams: Solid wood and laminated beamsAdvantage Benefit:
The back-toothed saw blade makes it easier to reverse in the wood - particularly easy when the saw blade is blocked with the mechanical brake. The spring pre-tensioning of the lower guide roller ensures quick and easy blade changes. With voltage drop switch to prevent uncontrolled restarting after a power interruption. The unique swivelling saw blade guide enables perpendicular cuts up to 90 mm deep without the second saw blade touching the material, e.g. in the case of sheeting.
Technical data:
Cutting depth 305 mm 1 belt side swivelling 0 - 30 ° Nominal idle speed 650 - 1550 1/min Nominal power consumption 2250 W Weight 13.7 kg Universal motor 230 V / 50 Hz Cutting speed 6.9 - 16.6 m/s
Scope of delivery:
1 saw blade, 8 mm wide, 4 teeth with back serration 1 saw blade, 8 mm wide, 4 teeth per inch 1 saw blade, 6 mm wide, 4 teeth per inch 1 handle for two-man operation; order no. 203824 1 rip fence; order no. 039386 1 connector complete with 10 m plug; order no. 087863
