Description
- NEW -
DESCRIPTION
- Closed substructure with high stability
- Safe and smooth saw cuts in wood
- Heavy, tilting cast-iron worktable with polished surface
- Powerful motor
- Safety switch stops the machine when the door is opened and prevents unintentional restarting and starting
- Grey cast iron flywheels ensure smooth running
- Set cutting width can be conveniently read on a scale
TECHNICAL DATA
Dimensions and weights
- Length (product) approx. 760mm
- Width/depth (product) approx. 760mm
- Height (product) approx. 1740mm
Suction connection
- Suction nozzle diameter 100mm
Work table(s)
- Work table length 500mm
- Worktable width 395mm
- Worktable height 32mm
- Work table inclination 0 - 45°
- Sliding carriage length 200mm
- Sliding carriage width 100mm
Electrical data
- Supply voltage 230V
- Mains frequency 50Hz
- Input power 1.5kW
- Output power 1.0kW
Cutting areas
- Cutting height max. 90°200mm
- Cutting width max. with stop 250 mm
- Cutting width max. without stop 375mm
Band saw blade
- Saw blade speed(s) 600m/min
- Flywheel diameter 400mm
- Saw blade length 2950mm
- Saw band width 16mm
- Saw blade width max .20mm
- Saw blade thickness 0.52mm
SCOPE OF DELIVERY
- On-board tool
Angle stop
Rip fence
Item number: 5902441
