Description
NEW
Description of the
- Ideal for ambitious modellers
and do-it-yourselfers
- Die-cast aluminium flywheels with
Special covering
- Grey cast iron work table can be swivelled up to 45
- Equipped with precise 3-roller saw blade
above and below the belt guide
Table
- Aluminium longitudinal stop with quick clamping
precisely adjustable with the aid of a magnifying glass and
Millimetre scale
- Two adjustable belt speeds
Technical data:
Dimensions and weights
Length approx. 870 mm
Width/depth approx. 690 mm
Height approx. 1715 mm
Weight approx. 76 kg
Dust extraction connection
Suction nozzle diameter 100 mm
Work table(s)
Length 545 mm
Width 515 mm
Height 1020 mm
Inclination 0 - 45 °
Electrical data
Input power 1.1 kW
Supply voltage 230 V
Band saw blade
Speed(s) 370 / 800 m/min
Length 2560 mm
Width 12.7 mm
Thickness 0.5 mm
Cutting areas
Cutting height max. 90° 225 mm
Cutting height max. 45° 145 mm
Cutting width max. with stop 255 mm
Cutting width max. without stop 340 mm
Scope of delivery
- Band saw blade
- Longitudinal stop with magnifying glass
- Mitre fence
- LED work light
- Push stick
- Underframe
