Description
with 7 spindles
Used
Machine tested, test run
Adjustments checked, lubricated
Make Hemag
Milling rotor type 190
Machine no. 703134
Motor 7.5 kW
Mechanical brake
Speed levels 3
Right-left run
Spindle 7 pieces
Spindle diameter 30 mm
Tool diameter max. in milling fence 210 mm
Tool diameter max. in the machine 140 mm
Table size 1300 mm x 1050 mm
Extendable frame support
Milling fence with fine adjustment
Suction connection D 120 mm
Space requirement approx. 1300 mm x 1100 mm x 1200 mm
Weight approx. 1100 kg
Total connected load 7.5 kW
Storage location 97447 Gerolzhofen, free loaded, unpacked
Handover in as-is condition as inspected,
without guarantee and warranty
