Description
- NEW -
Hofmann AHW 513
Technical data:
Planing width mm 510
Table height mm 877
Feeding table length mm 1500
Optional mm 2000
Length of take-off table mm 1500
Optional mm 2000
Blade shaft flight circle Ø mm 125
Max. Chip removal mm 8
Min. workpiece length mm 300
Min. workpiece width mm 20
Max. Workpiece width mm 500
Motor power kW 5.5
Speed of the cutter head
Tersa 1/min 5000
Helix 1/min 5800
Suction nozzle Ø mm 140
