Description
incl. suction bell
with controlled feed roller
Used
Make Guilliet
Type KXY
Year of construction 1993
Machine no. 2841
GS wood dust tested
Number of spindles 4
Spindle arrangement u-re-li-o
Motors 3.7 kW
Planing width approx. 30-180 mm
Planing height approx. 6-120 mm
Engine brakes
Table length approx. 2000 mm
Knife system Strip moulding knives
Demonstration cutter
Cardan feed
Pneumatic pressure of the feed roller - Cycle-controlled feed
Protective cover
Moving in before dressing
Feed speed 12 m/min.
Electric adjustment of thickness shaft
Digital displays height - width
Suction connection 250 mm / 3 x 120 mm / 1 x 140 mm
Space requirement approx. 3200 mm x 1200 mm x 1500 mm
Weight approx. 1200 kg
Storage location 97447 Gerolzhofen, free loaded, unpacked
Handover in as-is condition, as inspected,
without guarantee and warranty
