Description
- NEW -
- Machine bed made from torsion-resistant
Grey cast iron for smooth running and precision
- Tailstock and headstock made of sturdy grey cast iron
- Spindle with high concentricity
- Three infinitely adjustable speed ranges
- With clockwise/anticlockwise rotation as standard
- 24 hole pitch with snap-in for
Locking the workpiece
- Tailstock sleeve with through hole
for machining long workpieces
- Simple fixing of the tailstock via
Quick-release lever
- Easily adjustable torsion steel support
- Machine bed, tailstock and
Headstock made from sturdy grey cast iron
- Stepless speed control
- LED speed display
- Right-left rotation
Technical data:
- Max. turning diameter 355 mm
- Speeds 250-720, 600-1700, 1200-3550 min1
- Speed levels 3
- Infinitely variable speed control
- Quill adjustment 70 mm
- PU 1
Dimensions and weights
- Length approx. 1055 mm
- Width/depth approx. 560 mm
- Height approx. 460 mm
- Weight approx. 50 kg
Electrical data
- Input power 0.75 kW
- Supply voltage 230 V
- Phase(s) 1 Ph
- Current type AC
- Mains frequency 50 Hz
Storage location 97447 Gerolzhofen
- free loading -
